MZEU15 Frewheel One Way Backstop Roller Clutch Bearing
  • MZEU15 Frewheel One Way Backstop Roller Clutch Bearing
  • MZEU15 Frewheel One Way Backstop Roller Clutch Bearing

MZEU15 Frewheel One Way Backstop Roller Clutch Bearing

Place of Origin CHINA
Brand Name SUMA
Certification ISO SGS
Model Number MZEU15
Product Details
Product Name:
Roller Clutch Bearing MZEU15
Bearing Supported:
YES
Material:
Bearing Steel GCr15
Size:
15*68*52mm
Torque Capacity:
100Nm
Warranty:
1 Year
Package:
Carton Box / Wooden Box
OEM:
Accept
High Light:

MZEU Roller Clutch Bearing

,

GCr15 Roller Clutch Bearing

,

MZEU One Way Roller Bearing

Payment & Shipping Terms
Minimum Order Quantity
1
Price
USD80-USD110 PER PIECE
Packaging Details
Carton Box / Wooden Box
Delivery Time
7-15 Days
Payment Terms
L/C, D/A, D/P, T/T, Western Union,Paypal
Product Description

MZEU15 Freewheel One Way Backstop Roller Clutch Bearing



Features:



  • We recommend a Shaft tolerance of h7, and ISO R773 (DIN 6885.1) keyway is standard.
  • We recommend a tolerance of E H7 for the sprocket and other parts.
  • Clean the surface of both ends of the outer race and the contact surfaces of the flange, sprocket and the other parts.
  • For Model No. MZEU90 to MZEU150, apply seal adhesive to the surface of the outer race at both ends.
  • Model No. MZEU12 to MZEU80 are pre-greased and require no lubrication. The operational temperature range is -40C to +40C. Model No MZEU90 to MZEU150 require oil lubrication.
  • Model No. MZEU12 to MZEU80 sprockets and other torque transmitting factors can be used with the standard flange.



  • When installing standard flanges, sprockets and other equipment to the clutch fit them around the bearings and screw the bolts into both ends of the outer race.
  • By installing both the flange and sprocket on the opposite side, the direction of rotation can be changed.
  • When mounting the clutch onto the shaft, apply pressure to inner race but never to the outer race.
  • For high speed Indexing applications (More than 50 c/m) a strong spring type isrecommended.



Dimensions and Capacities

MZEU15 Frewheel One Way Backstop Roller Clutch Bearing 0


Model

Torque
Capac







Max. Overrunning

Drag
Torque

Bore Size

Keyway

A

B

C

D

E

F

G

H-J

K

L

Weight
N·m r/min r/min N·m H7 Inner Race   h7   PCD           C (kg)
MZEU 12 (K) 60 2,000 1,000 0.20 12 4X1.8 42 62 20 51 42 20 27 3 - 05.5 - 0.8 0.5
MZEU 15 (K) 100 1,800 900 0.20 15 5X2.3 52 68 28 56 47 25 32 3 - M5 8 0.8 0.8
MZEU 20 (K) 245 1,600 700 0.29 20 6X2.8 57 75 34 64 55 30 39 4 - M5 8 0.8 1.2
MZEU 25 (K) 425 1,600 600 0.33 25 8X3.3 60 90 35 78 68 40 40 4 - M6 10 0.8 1.8
MZEU 30 (K) 735 1,500 500 0.39 30 8X3.3 68 100 43 87 75 45 48 6 - M6 10 1.0 2.6
MZEU 35 (K) 1,015 1,400 300 0.49 35 10X3.3 74 110 45 96 80 50 51 6 - M6 12 1.0 3.2
MZEU 40 (K) 1,350 1,400 300 0.59 40 12X3.3 86 125 53 108 90 55 59 6 - M8 14 1.3 4.8
MZEU 45 (K) 1,620 1,400 300 0.69 45 14X3.8 86 130 53 112 95 60 59 8 - M8 14 1.3 6.2
MZEU 50 (K) 2,070 1,300 250 0.79 50 14X3.8 94 150 64 132 110 70 72 8 - M8 14 1.3 8.2
MZEU 55 (K) 2,400 1,300 250 0.88 55 16X4.3 104 160 66 138 115 75 72 8 - M10 16 1.5 9.5
MZEU 60 (K) 2,950 1,200 250 0.98 60 18X4.4 114 170 78 150 125 80 89 10 - M10 16 1.5 12.3
MZEU 70 (K) 4,210 1,100 250 1.27 70 20X4.9 134 190 95 165 140 90 108 10 - M10 16 1.8 18.1
MZEU 80 (K) 5,170 800 200 1.38 80 22X5.4 144 210 100 185 160 105 108 10 - M10 16 1.8 23.1
MZEU 90 (K) 12,000 450 150 4.70 90 25X5.4 158 230 115 206 180 120 125 10 - M12 20 2.0 28.1
MZEU100 (K) 17,600 400 130 5.39 100 28X6.4 182 270 120 240 210 140 131 10 - M16 24 2.0 46.3
MZEU130 (K) 24,500 320 110 6.76 130 32X7.4 212 310 152 278 240 160 168 12 - M16 24 2.5 70.2
MZEU150 (K) 33,800 240 80 8.13 150 36X8.4 246 400 180 360 310 200 194 12 - M20 32 2.5 146.3

Mounting and Coupling

MZEU15 Frewheel One Way Backstop Roller Clutch Bearing 1





Pictures

MZEU15 Frewheel One Way Backstop Roller Clutch Bearing 2

MZEU15 Frewheel One Way Backstop Roller Clutch Bearing 3



MZEU15 Frewheel One Way Backstop Roller Clutch Bearing 4
