GF Series GF12 One Direction Bearing 20Nm Roller Clutch Bearing

Large Image : GF Series GF12 One Direction Bearing 20Nm Roller Clutch Bearing

Product Details:

Place of Origin:	CHINA
Brand Name:	SUMA
Certification:	ISO SGS
Model Number:	GF12

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	USD50-USD80 PER PIECE
Packaging Details:	Carton Box
Delivery Time:	10-15 Days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, Paypal
Supply Ability:	1000PCS Per Month

Contact Now

GF Series GF12 One Direction Bearing 20Nm Roller Clutch Bearing

Description

Product Name:	Roller Clutch Bearing GF12	Material:	GCr15 Bearing Steel
Rotation Speed:	1000RPM	Unit Weight:	0.1Kg
Warranty:	1 Year	Size:	123720mm
Torque Capacity:	20Nm	OEM:	Accept
Highlight:	GF12 Roller Clutch Bearing , 20Nm Roller Clutch Bearing , GF12 One Way Clutch

GF12 1 Directional 20Nm Roller Clutch Bearing

Dimensions and Capacities

GF Series GF12 One Direction Bearing 20Nm Roller Clutch Bearing 0

Type	dH7	Dn6	L	s	D1	D2	b	t	Weight	Inner ring	Outer ring	TKN	Drag torque
	dH7	Dn6	L	s	D1	D2	b	t	Weight	freewheels/	freewheels/	TKN	Drag torque
	mm	mm	mm	mm	mm	mm	mm	mm	Kg	overruns min-1	overruns min-1	Nm	Ncm
GF 8	8	37	20	1	20	30	6	3	0.1	1000	1000	20	0.09
GF 9	9	37	20	1	20	30	6	3	0.1	1000	1000	20	0.09
GF 12	12	37	20	1	20	30	6	3	0.1	1000	1000	20	0.11
GF 15	15	47	30	1	26	37	7	3.5	0.3	900	900	78	0.15
GF 20	20	62	36	1	37	52	8	3.5	0.6	700	700	188	0.18
GF 25	25	80	40	-	40	68	9	4	1.2	2100	3600	250	0.36
GF 30	30	90	48	-	45	75	12	5	1.8	1700	3200	500	0.4
GF 35	35	100	53	-	50	80	13	6	2.4	1500	3000	680	0.6
GF 40	40	110	63	-	55	90	15	7	3.3	1200	2600	1115	0.84
GF 45	45	120	63	-	60	95	16	7	4	1000	2400	1500	0.94
GF 50	50	130	80	-	70	110	17	8.5	5.7	800	2100	2375	1.28
GF 55	55	140	80	-	75	115	18	9	6.5	750	2000	2500	1.5
GF 60	60	150	95	-	80	125	18	9	8.9	650	1900	4250	1.6
GF 70	70	170	110	-	95	140	20	9	13.5	550	1800	5875	3.6
GF 80	80	190	125	-	110	160	20	9	19	500	1600	10000	3.6
GF 90	90	215	140	-	120	180	24	11.5	27.2	450	1400	17350	6.8
GF 100	100	260	150	-	140	210	28	14.5	44.5	350	1300	19750	8.8
GF 130	130	300	180	-	160	240	32	17.5	68	250	1000	35000	12.5
