NKIS 0.007Kg GCr15 Yoke Type Track Roller Bearing

Basic Information
Place of Origin: CHINA
Brand Name: SUMA
Certification: ISO SGS
Model Number: NA495
Minimum Order Quantity: 1
Price: USD9-USD11 PER PIECE
Packaging Details: Roll pack + Carton Box
Delivery Time: 2-5 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union,Paypal
Supply Ability: 100000 PCS PER MONTH
Product Name: Yoke Type Track Roller Bearing NA495 Material: Bearing Steel GCr15
Size: 5*13*10mm Package: Roll Pack + Carton Box
Warranty: 6 Months OEM: Accept
Weight: 0.007Kg Port: Shanghai Ningbo
High Light:

0.007Kg Yoke Type Track Roller Bearing

,

NKIS Yoke Type Track Roller Bearing

,

GCr15 Cam Roller Track

NKIS 0.007Kg GCr15 Yoke Type Track Roller Bearing



Cam followers and track rollers from Grainger can withstand a variety of mechanical applications. Choose from assorted cam follower types, including full complement needle rollers, stud, heavy stud, crowned and yoke.



Dimensions and Capacities

NKIS 0.007Kg  GCr15 Yoke Type Track Roller Bearing 0

Shaft
Diameter
Bearing Designation Mass
Approx
Boundary Dimension Basic Loading Limiting
Speed
Current
code
Original
code
d Fw D B Dynamic Static Oil
mm g mm N rpm
5 NA495   7 5   13 10 2670 2350 34000
NA495TN   7 5   13 10 2670 2350 34000
6 NA496   9 6   15 10 3150 3000 32000
7 NA497   12 7   17 10 3600 3650 30000
8 NKI8/16     8 14 25 16 12400 11300 21500
NA498   16 8   19 11 4300 3950 28000
9 NKI9/12   16.6 9 12 19 12 6200 7000 21700
NA499   17 9   20 11 4850 4900 26000
NKI9/16   21.9 9   19 16
10 NKI10/16   27.3 10 14 22 16 9800 10500 196500
NA4900 4524900 21 10 14 22 13 8000 9000 23700
NA6900 6534900 38.4 10 14 22 22 9000 11000 23700
12 NA4901 4524901 25.1 12 16 24 13 9000 10800 20000
NKI12/20   39 12 16 24 20 14000 18400 21000
NA6901 6534901 44.5 12 16 24 22 6000 21600 20000
NKIS12   58 12 16 30 16 16000 17000 20000
NA12*32*15V     12   32 15
15 NKI15/16   38 15 19 27 16 8800 12800 19100
NKI15/20   45.7 15 19 27 20 12300 19000 19100
NA4902 4924902 32 15 20 28 13 6400 9000 18000
NA6902 6534902 61.6 15 20 28 23 13100 20900 18000
NKIS15   90 15 22 35 20 23500 24000 17000
NA5902   52 15 20 28 18
NA153212     15   32 12
74802 74802   15   36 25.4
16 NKIS16     16   28 16 13000 17400 22000
NA16*36*24     16   36 24
17 NKI17/16   41.4 17 21 29 16 13000 18200 20000
NA4903 4544903 32.8 17 22 30 13 7000 10000 17000
NA6903 6534903 68.2 17 22 30 23 14400 24900 17000
NA5903   56 17 22 30 18 15200 21700 18000
NA17     17   37 20
20 NKI20/16   48.5 20 24 32 16 10800 17000 16700
NA4904 4524904 70.2 20 25 37 17 21000 25000 17000
NKIS20   119 20 28 42 20 28000 35500 15000
NA6904 6254904   20 25 37 30 36000 51000 17000
NA5904     20 25 37 23
22 NKI22/16   50 22 26 34 16 15300 23600 17000
NA49/22   76 22 28 39 17 22000 29500 15000
NA69/22   130 22 28 39 30 37500 55000 15000
NA223934     22 28 39 34
23 NA2020     23   42 22
25 NKI25/30   115 25 29 38 30 31500 56000 14000
NA4905 4524905 76 25 30 42 17 23600 31500 14000
NA6905 6534905 138 25 30 42 30 29000 59000 14000
NKIS25   160 25 32 47 22 32000 55000 13000
  F-208277   25 32 47 22
NKI25/20     25 29 38 20 21900 34000 15000
NA5905   139 25 30 42 23 30500 43000 13000
28 NA49/28 45449/28 98 28 32 45 17 24000 33500 14000
NA69/28   170 28 32 45 30 23000 63000 14000
NKI28/20     28 32 42 20 25000 37500 14000
30 NA4906 4544906 115 30 35 47 17 25000 35500 13000
NA5906 6534906 152 30 35 47 23
NA6906     30 35 47 30 43500 71000 13000
NKI30/20     30 35 45 20 24000 42500 13000
NKI30/30     30 35 45 30 36500 69000 13000
32 NKI32/20     32 37 47 20 24900 43900 12000
  TAFI324720   32 40 47 20 24900 43500 12000
NA49/32 45449/32 150 32 40 52 20 24900 43500 12000
NA69/32 66349/32 272 32 40 52 36 100000 100000 11000
35 NKI35/30   165 35 40 50 30 39000 79000 11000
NA4907 4524907 151 35 42 55 20 19800 41500 11000
NA6907 6534907 301 35 42 55 36 26000 60500 11000
NKIS35   220 35 43 58 22 33000 56000 9500
NA5907   256 35 42 55 27
40 NKI40/20   124 40 45 55 20 22000 48000 10000
NKI40/30   184 40 45 55 30 35000 86000 10000
NA4908 4544908 240 40 48 62 22 42000 65000 8500
NA6908   401 40 48 62 40 64000 112000 8500
NA5908   348 40 48 62 30 53000 925000 8500
42 NKI42/20   138 42 47 57 20 26000 52500 9500
45 NKI45/25   218 45 50 62 25 36000 70000 8500
NKI45/35   289 45 50 62 35 41500 102000 8500
NA4909 4544909 260 45 50 68 22 37000 96500 8000
NA6909 6534909 479 45 50 68 40 61500 123500 8000
NKIS45   306 45 55 72 22 43000 71000 7500
NA5909   396 45 50 68 30





Shaft
Diameter
Bearing Designation Mass
Approx
Boundary Dimension Basic Loading Limiting
Speed
Current
code
Original
code
d Fw D B Dynamic Static Oil
mm g mm N rpm
80 NA4916 4544916 870 80 90 110 30 81000 170500 5500
NA6916 6534916 1510 80 90 110 54 130500 280600 5000
NKI80/35     80 90 110 35 103000 208000 5000
85 NKI85/26     85 95 115 26 73000 137000 4800
NKI85/36   1040 85 95 115 36 10700 223000 4800
NA4917 4544917 1250 85 100 120 35 111000 237000 4600
NA6917 6534917 2200 85 100 120 63 166000 400000 4600
90 NKI90/26     90 100 120 26 26000 146000 4600
NA4918 4544918 1312 90 105 125 35 114000 250000 4600
NA6918 6534918 2310 90 105 125 63 172000 425000 4600
95 NA4919 4544919 1371 95 110 130 35 116000 260000 4200
NA6919 6534919 2500 95 110 130 63 174000 440000 4200
NKI95/26     95 105 125 26 78000 115000 4200
NKI95/36     95 105 125 36 114000 250000 4200
100 NA4920 4544920 1900 100 115 140 40 12000 274000 4000
NKI100/30     100 110 130 30 98000 210000 4000
110 NA4922 4544922 2070 110 125 150 40 132000 290000 3700
NA4822   1080 110 120 140 30 94000 216000 3900
120 NA4924 4544924 2860 120 135 165 45 181000 890000 3400
NA4824   1170 120 130 150 30 99000 239000 3600
130 NA4926 4544926 3900 130 150 180 50 223000 470000 3100
NA4826   1810 130 145 165 35 118000 310000 3200
140 NA4928 4544928 4150 140 160 190 50 209000 50000 2900
NA4828   1920 140 155 175 35 120000 325000 3000
150 NA4830   2720 150 165 190 40 152000 400000 2800
160 NA4832   2890 160 175 200 40 160000 435000 2700
170 NA4834   3960 170 185 215 45 185000 510000 2500
180 NA4836   4200 180 195 225 45 194000 550000 2400
190 NA4838   5600 190 210 240 50 227000 690000 2300
200 NA4840   5840 200 220 250 50 230000 720000 2200
220 NA4844   6380 220 240 270 50 234000 790000 2000
240 NA4848   10000 240 265 300 60 355000 1080000 1800
260 NA4852 4524852 11300 260 285 320 60 37000 1160000 1700

Pictures

NKIS 0.007Kg  GCr15 Yoke Type Track Roller Bearing 1

NKIS 0.007Kg  GCr15 Yoke Type Track Roller Bearing 2
