Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating

Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating

  • Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating
  • Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating
  • Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating
  • Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating
  • Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating
  • Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating
Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating
Product Details:
Place of Origin: Jiangsu, China
Brand Name: SUMA
Model Number: CK-A3072
Payment & Shipping Terms:
Minimum Order Quantity: 2
Price: $8-10
Contact Now
Detailed Product Description
Precision Rating: P0 Seals Type: Sealed
Material: Bearing Steel Torque Range: 54-2000Nm
Thickness Range: 23-52mm Overrunning Speed: 1750-420 Rpm (inner Race), 500-150 Rpm (outer Race)
Outer Race Diameter: 42-180mm Inner Race Bore: 15-80mm
Weight Range: 0.17-7.4kg Surface Treatment: Anti-oxidizing Paint
Bearing Type: Sprag Keyed Shaft: Yes
Lubrication: Grease Lubricated Load Support: Requires Bearings For Axial/radial Loads
Housing Tolerance: Same As Bearing Housing Diameter
Highlight:

54-2000Nm Torque One Way Clutch Bearing

,

23-52mm Thickness Sprag Type Clutch Bearing

,

P0 Precision Rating Freewheel Bearing

One Way Freewheel Bearing Sprag Type CKA 3072 / CK-A 3072
Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating 0 Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating 1
Product Specifications
Model CK-A series
Torque (Nm) 54-2450
Overrunning speed (rpm) Inner race: 1750-420
Outer race: 500-150
Outer race size (mm) Diameter: 42-180
Thickness: 23-52
Inner race size (mm) Bore size: 15-80
Thickness: 24-52
Weight (Kg) 0.17-7.4
Product Description
The CK-A series sprag type one way freewheel clutch bearing is a non-bearing supported unit requiring separate bearings for axial and radial load support. These units come pre-lubricated with grease and are typically installed adjacent to a bearing with matching housing diameter tolerance. Both inner and outer races feature keyed connections for secure shaft and hole mounting.
Technical Parameters
Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating 2
Model Nominal Torque [N.m] Overrunning Speed (r/min) Dimension [mm] Bearing Weight [kg]
Inner race Outer race Outer race Inner race
CK-A1542 54 1750 500 42 15 6302 0.17
CK-A3072 208 1050 300 72 30 6307 0.47
Mounting Example
Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating 3
Product Images
Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating 4 Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating 5 Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating 6 Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating 7 Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating 8
Packaging
Sprag Type One Way Clutch Bearing with 54-2000Nm Torque 23-52mm Thickness and P0 Precision Rating 9
