One Way Clutch Bearing
>
|
| Place of Origin | CHINA |
| Brand Name | SUMA |
| Model Number | CSK |
One Way Clutch Bearing is an effective backstop clutch, also known as One Way Bearing, CSK Bearing. It is widely used in industrial and agricultural machinery. It has a single row structure, and is made of steel with an inner diameter of 6-20mm and an outer diameter of 15-35mm. It can be packaged in cartons, wooden cases or pallets. The One Way Clutch Bearing is characterized by high quality, low noise, low vibration, long service life and easy installation. It is suitable for a variety of applications, such as conveyors, agriculture, construction, automotive, etc.
| Type | Size | Bearing series | Dimension | Bearing loads |
Weight [kg] |
Drag torque | ||||
| dynamic | static | |||||||||
| CSK(KK) |
d [mm] |
TKN1) [Nm] |
N max [min-1] |
D [mm] |
L [mm] |
C [kN] |
C0 [kN] |
TR [Ncm] |
||
| 8* | – | 2.5 | 15000 | 22 | 9 | 3.28 | 0.86 | 0.015 | 0.5 | |
| 10 | 6200 | 6.8 | 13000 | 30 | 9 | 4.5 | 1.56 | 0.032 | 0.36 | |
| 12 | 6201 | 9.3 | 10000 | 32 | 10 | 6.1 | 2.77 | 0.04 | 0.7 | |
| 15 | 6202 | 17 | 8400 | 35 | 11 | 7.4 | 3.42 | 0.06 | 0.9 | |
| 17 | 6203 | 30 | 7350 | 40 | 12 | 7.9 | 3.8 | 0.07 | 1.1 | |
| 20 | 6204 | 50 | 6000 | 47 | 14 | 9.4 | 4.46 | 0.11 | 1.3 | |
| 25 | 6205 | 85 | 5200 | 52 | 15 | 10.7 | 5.46 | 0.14 | 2 | |
| 30 | 6206 | 138 | 4200 | 62 | 16 | 11.7 | 6.45 | 0.21 | 4.4 | |
| 35 | 6207 | 175 | 3600 | 72 | 17 | 12.6 | 7.28 | 0.3 | 5.8 | |
| 40 | – | 325 | 3000 | 80 | 22 | 15.54 | 12.25 | 0.5 | 7 | |
| CSK…2RS | 8* | 2.5 | 15000 | 22 | 9 | 3.28 | 0.86 | 0.015 | 0.8 | |
| 10 | 6.8 | 13000 | 30 | 9 | 4.5 | 1.56 | 0.032 | 1.8 | ||
| 12 | - | 9.3 | 10000 | 32 | 14 | 6.1 | 2.77 | 0.05 | 3 | |
| 15 | 17 | 8400 | 35 | 16 | 7.4 | 3.42 | 0.07 | 4 | ||
| 17 | 30 | 7350 | 40 | 17 | 7.9 | 3.8 | 0.09 | 5.6 | ||
| 20 | 50 | 6000 | 47 | 19 | 9.4 | 4.46 | 0.145 | 6 | ||
| 25 | 85 | 5200 | 52 | 20 | 10.7 | 5.46 | 0.175 | 6 | ||
| 30 | 138 | 4200 | 62 | 21 | 11.7 | 6.45 | 0.27 | 7.5 | ||
| 35 | 175 | 3600 | 72 | 22 | 12.6 | 7.28 | 0.4 | 8.2 | ||
| 40 | - | 325 | 3000 | 80 | 27 | 15.54 | 12.25 | 0.6 | 10 | |
SUMA CSK One Way Clutch Bearing is designed to be used in a variety of applications, from industrial machines to automobiles, offering a reliable and durable solution for transmitting power and motion. This one-way bearing is manufactured with high quality material, and its outer diameter ranges from 15 to 35mm, while its width is between 7 and 18mm. It has a low vibration level, available in V1/V2/V3/V4, and two seals type, Open/2RS/ZZ. It comes in a Carton/Wooden Case/Pallet package for easy transport and storage.
The One Way Clutch Bearing from SUMA is designed to deliver superior performance in a wide range of applications, providing a reliable and durable solution for transmitting power and motion. It is manufactured with premium materials and can withstand extreme temperatures, shock, and vibration. It features a low vibration level and two seals type (Open/2RS/ZZ) for optimal performance. It has an outer diameter of 15 to 35mm and width of 7 to 18mm, and is supplied in a Carton/Wooden Case/Pallet package for easy transport and storage.
If you are looking for a reliable and durable One Way Clutch Bearing from a trusted brand, then the SUMA CSK One Way Clutch Bearing is the perfect choice for you. With its high quality material and superior performance, this one-way bearing is sure to provide you with the reliable and durable solution you need for your applications.
One Way Clutch Bearing Packaging and Shipping
Each One Way Clutch Bearing is securely packaged in a cardboard box with cushioning material to protect it from any kind of possible damage during shipping. The box is then placed inside a sturdy shipping envelope, which is marked with our logo and contact information.
For shipments within the continental United States, we generally use UPS or USPS for our deliveries. For international shipments, we generally use DHL or FedEx.
