Name: CSK8 CSK10 CSK12 One Way Clutch Bearing Freewheel Backstop Clutch
Brand: Changzhou Suma Precision Machinery Co., Ltd
SKU: CSK8 CSK10 CSK12
Price: 2.00 USD
Availability: InStock

Home Products Sprag Clutch Bearing

CSK8 CSK10 CSK12 One Way Clutch Bearing Freewheel Backstop Clutch

Product Details:

Place of Origin:	CHINA
Brand Name:	SUMA
Certification:	ISO
Model Number:	CSK8 CSK10 CSK12

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	USD2-USD2.5PER PIECE
Packaging Details:	White Box + Carton Box + Wooden Pallet
Delivery Time:	3-5 Days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, Paypal
Supply Ability:	20000PCS PER WEEK

Contact Now

Detailed Product Description

Material:	Gcr15 Bearing Steel	Torque Capacity:	2.5Nm
Rotation Speed:	15000RPM	Drag Torque:	0.5Ncm
Unit Weight:	0.015KG	Package:	White Box + Carton Box
OEM:	Accept	Delivery Time:	5-7 Days
Highlight:	CSK12 One Way Clutch Bearing , Freewheel Backstop One Way Clutch Bearing , Freewheel Backstop Clutch Bearing

CSK8 CSK10 CSK12 One-Way Clutch Bearing Freewheel Backstop Clutch

Dimensions and Capacities

CSK8 CSK10 CSK12 One Way Clutch Bearing Freewheel Backstop Clutch 0

Type	Size	Bearing series	DIMENSION						Bearing loads		Weight	Drag torque
Type	Size	Bearing series	DIMENSION						dynamic	static		Drag torque
CSK..P	d		TKN1)	nmax	D	L	b	t	C	C0		TR
	[mm]		[Nm]	[min-1]	[mm]	[mm]	[mm]	[mm]	[kN]	[kN]	[kg]	[Ncm]
	12	6201	9.3	10000	32	10			6.1	2.77	0.04	0.7
	15	6202	17	8400	35	11			7.4	3.42	0.06	0.9
	17	6203	30	7350	40	12			7.9	3.8	0.07	1.1
	20	6204	50	6000	47	14			9.4	4.46	0.11	1.3
	25	6205	85	5200	52	15			10.7	5.46	0.14	2
	30	6206	138	4200	62	16			11.7	6.45	0.21	4.4
	35	6207	175	3600	72	17			12.6	7.28	0.3	5.8
	40	–	325	3000	80	22			15.54	12.25	0.5	7
CSK..PP	15	6202	17	8400	35	11	2	0.6	7.4	3.42	0.06	0.9
	17	6203	30	7350	40	12	2	1	7.9	3.8	0.07	1.1
	20	6204	50	6000	47	14	3	1.5	9.4	4.46	0.11	1.3
	25	6205	85	5200	52	15	6	2	10.7	5.46	0.14	2
	30	6206	138	4200	62	16	6	2	11.7	6.45	0.21	4.4
	35	6207	175	3600	72	17	8	2.5	12.6	7.28	0.3	5.8
	40	–	325	3000	80	22	10	3	15.54	12.25	0.5	7
CSK..P-2RS	12	–	9.3	10000	32	14			6.1	2.77	0.05	3
	15	–	17	8400	35	16			7.4	3.42	0.07	4
	17	–	30	7350	40	17			7.9	3.8	0.09	5.6
	20	–	50	6000	47	19			9.4	4.46	0.145	6
	25	–	85	5200	52	20			10.7	5.46	0.175	6
	30	–	138	4200	62	21			11.7	6.45	0.27	7.5
	35	–	175	3600	72	22			12.6	7.28	0.4	8.2
	40	–	325	3000	80	27			15.54	12.25	0.6	10
