NFR40 GF40 1115 Nm Conveyor One Way Freewheel Roller Bearing
  • NFR40 GF40 1115 Nm Conveyor One Way Freewheel Roller Bearing
  • NFR40 GF40 1115 Nm Conveyor One Way Freewheel Roller Bearing

NFR40 GF40 1115 Nm Conveyor One Way Freewheel Roller Bearing

Place of Origin CHINA
Brand Name SUMA
Certification ISO SGS
Model Number GF40
Product Details
Product Name:
Roller Clutch Bearing GF40
Material:
GCr15 Bearing Steel
Rotation Speed:
2600RPM
Unit Weight:
3.3Kg
Warranty:
1 Year
Size:
40*110*63mm
Torque Capacity:
1115Nm
OEM:
Accept
High Light:

GF40 One Way Roller Bearing

,

1115 Nm One Way Roller Bearing

,

GF40 One Way Roller Clutch

Payment & Shipping Terms
Minimum Order Quantity
1
Price
USD50-USD200 PER PIECE
Packaging Details
Carton Box
Delivery Time
10-15 Days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, Paypal
Supply Ability
1000PCS Per Month
Product Description

               GF40 1115 Nm Conveyor One Way Roller Bearing



Features



 The GF Series Freewheels are self centring. From size 8 to size 20, centring is steel on steel, whilst from size 25 to 130, centring is ensured by 2 160 series bearings.

Torque foreces are transmitted from the shaft to the inner race by means of a keyway and from the outer race to the seat by means of front pullers.

 Shaft tolearances must be either h6 or j6, seating tolearances must be H7 or G7.

If no front pullers are used, the seating tolearance becomes K6.



Before being put onto service, the freewheels must be lubricated with suitable lubricants . Oil lubrication is essential when a high number of rotations in neutral is reached .



Dimensions and Capacities


Type dH7 Dn6 L s D1 D2 b t Weight Inner ring Outer ring TKN Drag torque
freewheels/ freewheels/
mm mm mm mm mm mm mm mm Kg overruns min-1 overruns min-1 Nm Ncm
GF 8 8 37 20 1 20 30 6 3 0.1 1000 1000 20 0.09
GF 9 9 37 20 1 20 30 6 3 0.1 1000 1000 20 0.09
GF 12 12 37 20 1 20 30 6 3 0.1 1000 1000 20 0.11
GF 15 15 47 30 1 26 37 7 3.5 0.3 900 900 78 0.15
GF 20 20 62 36 1 37 52 8 3.5 0.6 700 700 188 0.18
GF 25 25 80 40 - 40 68 9 4 1.2 2100 3600 250 0.36
GF 30 30 90 48 - 45 75 12 5 1.8 1700 3200 500 0.4
GF 35 35 100 53 - 50 80 13 6 2.4 1500 3000 680 0.6
GF 40 40 110 63 - 55 90 15 7 3.3 1200 2600 1115 0.84
GF 45 45 120 63 - 60 95 16 7 4 1000 2400 1500 0.94
GF 50 50 130 80 - 70 110 17 8.5 5.7 800 2100 2375 1.28
GF 55 55 140 80 - 75 115 18 9 6.5 750 2000 2500 1.5
GF 60 60 150 95 - 80 125 18 9 8.9 650 1900 4250 1.6
GF 70 70 170 110 - 95 140 20 9 13.5 550 1800 5875 3.6
GF 80 80 190 125 - 110 160 20 9 19 500 1600 10000 3.6
GF 90 90 215 140 - 120 180 24 11.5 27.2 450 1400 17350 6.8
GF 100 100 260 150 - 140 210 28 14.5 44.5 350 1300 19750 8.8
GF 130 130 300 180 - 160 240 32 17.5 68 250 1000 35000 12.5

Pictures

NFR40 GF40 1115 Nm Conveyor One Way Freewheel Roller Bearing 1
NFR40 GF40 1115 Nm Conveyor One Way Freewheel Roller Bearing 2

Package :

NFR40 GF40 1115 Nm Conveyor One Way Freewheel Roller Bearing 3
